Products > Vane pump > > Vickers Vane Pump 20V 25V 35V 45V
Product name : Vickers Vane Pump 20V 25V 35V 45V
Item : 106
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:
Vickers Vane Pump 20V 25V 35V 45V

Specification:

Series Size Delivery Max Pressure(Mpa) Max Speed(rpm) Min Speed(rpm)
20V     **20V 2 7.5(0.46) 14 1800 600
3 10(0.61)
4 13(0.79) 21
5 16.5(1.01)
6 19(1.16)
7 23(1.40)
8 27(1.67)
9 30(1.85)
10 32(1.95)
11 36(2.20)
12 40(2.44) 16
14 45(2.78) 14
25V      25**V   **25V 10 32.5(1.98) 17.5 1800 600
12 39(2.38)
14 45(2.78)
15 47(2.89)
17 55(3.36)
19 60(3.66)
21 67(4.13)
35V      35**V   **35V 21 67(4.13) 17.5 1800 600
25 81(4.94)
30 97(5.91)
32 101(6.16)
35 112(6.83)
38 121(7.37)
45V      45**V   **45V 42 138(8.31) 17.5 1800 600
45 147(8.95)
50 162(9.85)
57 181(11.05)
60 193(11.75)
66 212(12.93)
75 237(14.46) 14


Feartures:

Eaton/Vickers 20V Series Low Noise Industrial Intra-Vane Single Pump

The 20V series pumps are designed for medium pressure industrial applications. The intra-vane cartridge design provides long operating life, outstanding volumetric efficiency (more than 90%) and excellent serviceability. The super-quiet (as low as 62 dB(A) 12-vane system is ideal for the indoor industrial environment. The 22nd design is well known for reliability and versatility, and is used in industrial machinery all over the world.



Eaton/Vickers 20 V Series Vane Single Pump Features:
Pressure balanced vane design
Modular construction
Wide range of displacements
Double, triple and through drive pump options



Eaton/Vickers 20V Series Vane Single Pump Benefits:
-Low noise and long life
-Ease of repair and serviceability
-Wide range of applications
-Compact for limited space installation

What are the characteristics of the Vickers vane pump 20V19A-1A22R 20V2A-1B22R


1. The high-pressure Vickers vane pump 20V3A-1A22R uses a plug-in structure, which is composed of internal parts. It can replace the end cover, rotor, stator and vane of the oil distribution plate in a few minutes. The structure of the stator is a cylindrical hole.


2. The high-pressure Vickers vane pump 20V4A-1A22R uses precision round blades to reduce the stator pressure stress on the blades. The service life of the stator and blades is extended, and the design is very reasonable,


3. The stator of Vickers high-pressure vane pump
20V5A-1A22R adopts high-order non impact transition curve. The vane has a good stress state to ensure good contact between the vane and the stator, and to minimize the flow loss, pressure and flow pulsation, so that Vickers vane pump has a longer service time.


4. The stator and rotor of Vickers high pressure vane pump 20V6A-1A22R are eccentric. The blade can slide flexibly in the groove of the rotor.


5. This Vickers high pressure vane pump 25V15A-1C22R is called a single acting pump when the rotor rotates once and every time it sucks oil. Unbalanced pump is because the rotor is unbalanced by radial hydraulic pressure, bearing pressure. When the eccentricity between the rotor and the stator of Vickers vane pump 35V25A-1A22R is changed, the displacement of the pump changes, which can also be called variable displacement pump. Vane pump 35V30A-1A22R has the advantages that gear pump and piston pump (Plunger pump) do not have, which can be used for reference.
