Products > Gear pump > > Gear pump 0PF0.16L07B01*** series

Product name : Gear pump 0PF0.16L07B01*** series

Enlarge Image

Back

←[Previous Product] [Next Product]→

Details:

Gear pump 0PF0.16L07B01*** series

How to order:

0PF**L06B01LSS

0PF**L07B01LBF

	Displacement (ml/r)	Pressure (bar)		Speed (r/min)			L (mm)	SS	Inlet (mm)
	Displacement (ml/r)	Rated	Peak	Rated	Max	Min	L (mm)	L1(mm)	Inlet (mm)
0PF0.16L07B01***	0.16	200	250	2000	6000	800	58.2	30.8	G1/4
0PF0.25L07B01***	0.25	200	250	2000	6000	800	59	31.3
0PF0.38L07B01***	0.38	200	250	2000	6000	800	60.3	31.9
0PF0.50L07B01***	0.5	200	250	2000	6000	800	61	32.3
0PF0.75L07B01***	0.75	200	250	2000	6000	800	63.5	33.5
0PF1.00L07B01***	1	200	250	2000	6000	800	66	34.8
0PF1.25L07B01***	1.25	200	250	2000	5000	800	68.5	36
0PF1.50L07B01***	1.5	200	250	2000	4500	800	70	37
0PF1.75L07B01***	1.75	200	250	2000	4000	800	73	38.3
0PF2.00L07B01***	2	160	200	2000	3500	800	75.5	39.5
