Products > Hydraulic valves > > DG4V5 Series DG4V5-20-DC Vickers Type Solenoid Valve
Product name : DG4V5 Series DG4V5-20-DC Vickers Type Solenoid Valve
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:
DG4V5 Series DG4V5-20-DC Vickers Type Solenoid Valve

How to order:














[Technical Data]
General Data
The total weight of one solenoid valve(with two solenoids)
kg
DC: 6.55      AC:5.7
The total weight of one solenoid valve (with one solenoid)
kg
DC: 5.00      AC:4.2
Installation site

Optional position
Operating temperature
-20~+50(adopt NBR seal ring )
Hydraulic Data
Maximum working oil pressure
Oil port P,A and B
MP a
31.5
The highest dynamic oil pressure T cavity can bear
MP a
16
The highest static oil pressure T cavity can bear
MP a
16
Rated flow
1/min
80
Maximum flow
1/min
120
Liquid medium

Mineral hydraulic oil, Phosphate hydraulic oil
The oil temperature range
-20~+80
The oil cleanliness

ISO4572:β10≥75NAS1638:Class 9

Electrical Data
Voltage category


DC
AC
RAC(coil with a rectifier component)
Duty cycle
ED
100%
Allowed voltage fluctuation range
%
-10~+10
The reserving and resetting time
ms
On:160 off:120
on:25 off:30
on:160 0ff: along with the change of phase angle when electric disconnects
Coil insulation class

Classs B
Class H
Class B
The maximum operating temperature coil allowed
135
180

135
Coil weight
kg
1.0
0.7

1.0
voltage
V
12
24

110
220


Power rate
Hz



50
50
50/60
50/60
Power consumption
W
38
38
38
40
40
40
40
Coil resistance(20℃)
ohm
38
15.2
319
28
55
59.5
238
Operating current(20℃)
A
3.15
1.58
0.35
0.22
0.42
0.47
0.24

Other solenoid valve models have:


  • EATON VICKERS VICKERS solenoid valve dg4v-5-6cj-m-u-h6-20




    EATON's fluid power products are widely used in earthmoving machinery, agriculture, construction, aviation, mining, forestry, utilities and material handling. Eaton is a leading manufacturer of diversified industrial products with a reputation for advanced technology and reliable quality in the industrial field. It employs 55,000 people in more than 125 countries on six continents. Annual sales of $9.8 billion. Products range from automobiles, trucks, heavy equipment, civil aviation, defense, military, residential, telecommunications and data transmission, industrial equipment and public facilities, commercial and government institutions, and various fields of sports and recreation.

    Vickers fluid power is a widely recognized leader in today's hydraulic market, leading the industry in product development, technical strength, product quality and after-sales service. Headquartered in Eden Prairie, Minnesota, USA, it has 22 factories.

    Today's wigels are more powerful than ever. Eaton, vickers, char-lynn, aeroquip, and hydroline are part of the Eaton, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, vickers, and vickers brands.

    Major markets for VICKERS fluid power include construction, agriculture, traditional industries, metallurgy, mining, shipbuilding, horticulture, and wind power. Depending on its incomparable global distribution network, customers can enjoy the quick and convenient service provided by wigth fluid power wherever they are. From traditional industry to walking machinery, from single component to the whole hydraulic system, wigth fluid power is your reliable partner in hydraulic products all over the world.

    With the advantages of fast delivery and good after-sales service, we have also specially built the stock of common spare parts for VICKERS.

    Other solenoild valve models : DG5V-8-H-6C-T-VM-U-H-10

    DG5V 7 6C T VM U H7 30

    DG4V-3-2A-M-U-H7-60

    DG4V-3-2A-M-U-C6-60

    DG4V-3-6C-MU-B6-60

    DG4V-3-2AL-M-U-H7-60
    DG4V-3-2A-M-U-H7-60
    DG4V-3-22A-M-U-H7-60
    DG4V-3-0A-M-U-H7-60
    DG4V-3-2B-M-U-H7-60
    DG4V-3-6B-M-U-H7-60
    DG4V-3-2C-M-U-H7-60
    DG4V-3-6C-M-U-H7-60
    DG4V-3-7C-M-U-H7-60
    DG4V-3-3C-M-U-H7-60
    DG4V-3-31C-M-U-H7-60
    DG4V-3-33C-M-U-H7-60
    DG4V-5-0A-M-U-H6-20
    DG4V-5-2AJ-M-U-H6-20
    DG4V-5-2CJ-M-U-H6-20
    DG4V-5-3CJ-M-U-H6-20
    DG4V-5-6CJ-M-U-H6-20
    DG5S4-042A-M-U-H7-71
    DG5S4-042B-T-M-U-H7-71
    DG5S4-042C-M-U-H7-71
    DG5S4-042C-T-M-U-H7-71
    DG5S4-043C-M-U-H7-71
    DG5S4-0431C-M-U-H7-71
    DG5S4-046C-M-U-H7-71
    DG5V-8-S-2A-M-U-H7-10
    DG5V-8-S-2C-M-U-H7-10
    DG5V-8-S-3C-M-U-H7-10
